Toldi fence - ST19
Aesthetic, modern look
Our product ST19 Toldi, reinforced with special triangular ribs, results in enhanced safety and rigidity with a minimum of 2 and a maximum of 4 bends per panel. The product is available from a height of 103 cm to a height of 243 cm, and up to a height of 300 cm on special request. Convincing arguments in favor of the panel fence:
The 3D panel fence is now a particularly popular solution for modern family houses and industrial areas, because it offers many advantages, while its construction is also fast. The panels are made of galvanized steel, and Steelvent always provides them with a powder-coated coating, so they are extremely durable and withstand weather conditions well. The surface protection is UV-stable, so even sunlight does not fade, and the fence retains its appearance and resistance for a long time. The rigid structure and three-dimensional design not only give a modern, aesthetic appearance, but also increase safety, because it makes climbing over much more difficult. Its clean style easily fits into both residential and industrial environments. If you want a truly durable solution, it is worth considering a design made of thicker wire, up to 5 mm thick.
Another advantage is that 3D panel fences can be installed simply and quickly, and they usually do not require special tools or complicated operations — regardless of this, our company always recommends involving a professional. Due to the manufacturing solution, they require little maintenance, so they are a convenient and practical choice in the long term. They are available in several sizes and colors, so they can be easily adapted to the environment and individual needs. Since they are made of steel, they are completely recyclable, which is also an advantage from an environmentally conscious point of view. Their price-performance ratio is favorable: they provide a long service life with a relatively moderate initial cost. Their modular design also allows the panels to be easily replaced, expanded, and even moved to another location if necessary.
Application areas
It is an extremely easy-to-install, long-lasting, maintenance-free fence type that is particularly suitable for industrial and residential use.
General characteristics
Vertical thread spacing 50mm, horizontal thread spacing 200mm, so the pitch is 50x200 mm. The boards are available with a light, i.e. 4mm, and normal, i.e. 5mm wire diameter.
- 50x200 mm
- 60x200 mm
- 50x100 mm on request
Maximum surface protection
Surface treatments:
- Galvanized
- Galvanized + UV stable powder coated
- Subsequently hot-dip galvanized
The Steelvent ST19 Toldi 3D panel fence is made of high-quality galvanized steel wire according to ISO standards. The strength of the fence is primarily determined by the diameter of the wire and the density of the mesh: it is typically made of 3.8 mm wire, while reinforced versions are 4.8 mm. The wires are vertically spaced 55 mm and horizontally 200 mm apart, meaning the spacing is 55×200 mm (5×20 cm). The welded, galvanized structure is coated with UV-resistant, baked powder coating, so the fence element receives outstanding protection against the weather for many years.
It is also worth noting that the panel fence will only be truly stable and safe if it is built with a quality post system. The Steelvent ST20 fence post is the solution for this, which is made of high-strength, galvanized 60×40 mm hollow section steel. The zinc layer is complemented by UV-stable powder coating, which further increases corrosion resistance. "Frugal" fence builders often choose cheap concrete posts or thin tubular posts solely because of their price — but we can provide premium Steelvent posts at a similar price level.
We should not take the fastening lightly either: the Steelvent bracket board fastener is used to attach the fence board to the post, which is made of stainless steel and high-strength, UV-resistant plastic, so it will not fade or deteriorate over time. Quality is a fundamental principle for us, which is why we do not recommend weak tubular or concrete posts or cheap, insecure fastening solutions. It is especially important to avoid using self-tapping or self-drilling screws (plate clamps) to secure the fence to the street front, as this solution can be dismantled in a matter of seconds.
Finally, it is important to note that many fence companies try to hide the fact that the vertical hole spacing of their fences is not 5 cm, but 6–7 cm, which results in cheaper production. However, “cheap meat is cheap”: we consider it appropriate if the standard 3D steel fence has a hole spacing of 5 cm, i.e. the distance between the vertical wires is 50–55 mm, not 60–65 mm. In our opinion, the latter already represents a compromise in the basic function of the fence.
Fence post
For the STEELVENT ST19 Toldi type fence system, we recommend ST20 posts with a cross section of 60 × 40 mm. The posts are manufactured in a diggable or fixed, base version. Their surface protection is the same as that of the fence panels. If required, a more massive post with a cross section of 60 x 60 mm can also be used.
Fixing, plinth
The fence panels are attached to the fence post using a Steelvent type panel attachment element (consisting of stainless steel and plastic elements). It is also possible to use a base element for the fence panels:
- 20 cm high
- 30 cm high
- 50 cm high
In the case of a base element, a base U profile must be used for the fence post.
Size chart and surface protection
| Height (mm) | 1200-1500 | 1700 | 2000 | 2200 | 2400 |
| Width | 2500 | 2500 | 2500 | 2500 | 2500 |
| Vertical pitch | 50 | 50 | 50 | 50 | 50 |
| Hot-dip galvanized afterwards | X | X | X | X | X |
| Hot-dip galvanized + powder coated | X | X | X | X | X |
“Normal”
5 mm wire diameter
| Height (mm) | 1200-1500 | 1700 | 2000 | 2200 | 2400 |
| Width | 2500 | 2500 | 2500 | 2500 | 2500 |
| Vertical pitch | 50 | 50 | 50 | 50 | 50 |
| Hot-dip galvanized afterwards | X | X | X | X | X |
| Hot-dip galvanized + powder coated | X | X | X | X | X |
* Nominal sizes, please contact us for exact sizes!
** Not in stock, made to order only, please contact us for details!
